A. Kağan KARABULUT, İ. İlknur UYSAL, MUZAFFER ŞEKER, Ali ACAR, Mustafa BÜYÜKMUMCU

İnsan fötusunda kalp kapakları gelişiminin ve aralarındaki ilişkinin ultrasonografi ve diseksiyon yöntemleri ile araştırılması

Amaç: insan fötuslarında kalp kapaklarının gelişiminin ultrasonografi ve diseksiyonla belirlenerek gestasyonel yaşla (GY) korelasyonunu araştırmak. Yöntem: Komplikasyonsuz ve tek fötuslu 48 gebede fötus kalp kapakları gelişimi prospektif olarak ultrasonografi ile değerlendirildi. GY'ları 23-39 hafta arasında değişen fötuslarda mitral, triküspit, aorta ve pulmoner kapak çapları ölçüldü. Ayrıca Anatomi Anabilim Dalı fetus kolleksiyonundan alınan ve GY'ları 14-40 hafta arasında değişen spontan abort 70 adet fötusta kalp kapakları ölçüldü. Ölçüm verileri ile GY arasındaki korelasyon değerlendirildi. Ayrıca, diseksiyon verileri cinsiyete göre karşılaştırıldı. Bulgular: Kalp kapakları gelişimi ile GY arasında pozitif korelasyon saptandı. Ultrasonografik verilere göre aorta ve triküspit kapak gelişim hızı, diseksiyon verilerine göre ise pulmoner kapak çapı haricindeki tüm parametrelerde gelişim hızı 2. trimestrda daha fazla bulundu. Pulmoner kapak çapı ile GY arasındaki korelasyonda trimestrlar arasında anlamlı bir farklılık saptanmadı. Ölçümler, cinsiyete göre bir farklılık göstermedi. Sonuç: insan fötus kalp kapaklarının gelişimine ait veriler, fötal kalp gelişiminin değerlendirilmesi ve konjenital kardiyak defektlerin doğum öncesi tanısında yararlı olabilir.

Anahtar Kelimeler:

Kalp kapakları, Fetal izleme, Fetal organ olgunlaşması, Gebelik yaşı, Gebelik, İleriye dönük çalışma, Ultrasonografi, Fetal gelişim

An investigation on the development of the valves of human fetal heart and their relationship by ultrasonography and dissection

Objective: Determination of the developmental pattern of the valves of human fetal heart by ultrasonography (USG) and dissection, and investigation of the correlation with the gestational age (GA). Methods: Development of the valves of the heart was evaluated in 48 pregnant women with uncomplicated single pregnancy prospectively by USG. GA was ranged from 23 to 39 weeks, and the diameter of mitral, tricuspit, aortic and pulmonary valves were measured. in addition, the diameter of the cardiac valves was measured in 70 spontaneously aborted human fetuses obtained from the fetus collection of Anatomy Department. G A was ranged from 14 to 40 weeks. The correlation was evaluated between measured values and the GA. in addition, the dissection data was compared regarding to sex. Results: There was a positive correlation between the development of the valves of heart and GA. The rate of increase in the diameter of the aorta and tricuspit valves measured by USG, and all parameters apart from the diameter of pulmonary valve measured by dissection were significantly higher in the 2nd trimester. There was no difference regarding to correlation ratio of trimesters between the pulmonary valve diameter and GA. The measurements did not show any difference regarding to sex. Conclusion: The values of the development of the valves of fetal heart may help the evaluation of fetal cardiac development and in the prenatal detection of congenital cardiac defects.

Keywords:

Heart Valves, Fetal Monitoring, Fetal Organ Maturity, Gestational Age, Pregnancy, Prospective Studies, Ultrasonography, Fetal Development,

PDF

___

Leslie J, Shen S, Thornton JC, Strauss L. The human fetal heart in the second trimester of gestation:A gross morphometric study of normal fetuses. Am J Obstet Gynecol 1983;145:312-6.
St John Sutton MG, Raichlen JS, Reichek N, Huff DS. Quantitative assessment of growth and function of the cardiac chambers in the normal human fetal heart: A pathoanatomic study. Circulation 1984;70:935-41.
Alvarez L, Aranega A, Saucedo R, Contreras JA. The quantitative anatomy of the normal human heart in fetal and perinatal life. Int J Cardiol 1987;17:57-72.
Kim HD, Kim DJ, Lee IJ, Rah BJ, Sawa Y, Schaper J. Human fetal heart development after mid-term:Morphometry and ultrastructural study. J Mol Cell Cardiol 1992;24(9):949-65.
Mandarim-de-Lacerda CA. Morphometry of the human heart in the second and third trimesters of gestation. Early Hum Dev 1993;35:173- 82.
Hutchins GM, Meredith MA, Moore GW. The cardiac malformations. Double inlet left ventricle and corrected transposition explained as deviations in the normal development of the interventricular septum. Hum Pathol 1981;12:242-50.
Figueria RR, Prates JC, Hayashi H. Development of the pars membranacea septi interventricularis of the human heart. II. Tickness change. Arch Ital Anat Embriol 1991;96:303-7.
Nguyen H, Leroy JP, Vallee B, Person H, Nguyen HV. The muscular atrioventricular septum. Bull Assoc Anat (Nancy) 1982;66:373-7.
Espinosa-Caliani JS, Alvarez-Guisado L, Munoz-Castellanos l, Aranega-Jimenez A, Kuri-Nivon M, Sanchez RS, et al. Atrioventricular septal defect:quantitative anatomy of the right ventricle. Pediatr Cardiol 1991;12:206-13.
Wenink AC. Quantitative morphology of the embryonic heart: An approach to development of the atrioventricular valves. Anat Rec 1992;234:129-35.
Hyett J, Moscoso G, Nicolaides K. Morphometric analysis of the great vessels in early fetal life. Hum Reprod 1995;10:3045-8
Jeanty P, Romero R, Cantraine F, Cousaert E, Hobbins JC. Fetal cardiac dimensions:A potential tool for the diagnosis of congenital heart defects. J Ultrasound Med 1984;3:359-64.
St John Sutton M, Gill T, Plappert T, Saltzman DH, Doubilet P. Assessment of right and left ventricular function in terms of force development with gestational age in the normal human fetus. Br Heart J 1991;66:285-9.
Mandorla S, Narducci PL, Bracalente B, Pagliacci M. Fetal echocardiography. A horizontal study of biometry and cardiac function in utero. G Ital Cardiol 1986;16:487-95.
Fernandez PL, Tamariz-Mantel MA, Maitre AMJ, Lopez ZM, Cazzaniga BM, Rico GF, et al. Heart growth in the normal human fetos: A two dimensional echocardiographic study. An Esp Pediatr 1996;44:475-81.
Rane HS, Purandare HM, Chakravarty A, Pherwani AV. Fetal echocardiography- norms for M- mode measurements. Indian Heart J 1990;42:351-5.
Veille JC, Sivakoff M, Nemeth M. Evaluation of the human fetal cardiac size and function. Am J Perinatol 1990;7:54-9.
Tan J, Silverman NH, Hoffman JI, Villegas M, Schmidt KG. Cardiac dimensions determined by cross-sectional echocardiography in the normal human fetus from 18 weeks to term. Am J Cardiol 1992;70:1459-67.
Smolich JJ. Ultrastructural and functional features of the developing mammalian heart: A brief overview. Reprod Fertil Dev 1995;7:451-61.
St John Sutton MG, Gewitz MH, Shah B, Cohen A, Reichek N, Gabbe S, et al. Quantitative assessment of growth and function of the cardiac chambers in the normal human fetus: A prospective longitudinal echocardiographic study. Circulation 1984;69:645-54.
Karabulut AK, Köylüoğlu B, Şeker M, Büyükmumcu M, Uysal İİ. Gebeliğin 2. ve 3. trimestrlarında insan fötuslarında ultrasonografi ve diseksiyonla kalp ölçümlerinin fötal büyüme ve gelişme açısından değerlendirilmesi. Morfoloji 2000;8:28-32.
Salbacak A, Uysal İİ, Büyükmumcu M, Karabulut AK. İnsan fötuslarında kalp gelişiminin ve kalbin morfolojik yapısının diseksiyon yöntemi ile araştırılması. Genel Tıp Derg 2000;10:155-70.
