Hakan DUMRUL, Selcuk SELİMLİ, Sezayi YILMAZ, Baris KORKMAZ

SPACE COOLING WITH GROUNDWATER PUMPED BY A SOLAR DRIVEN PUMP

In this study, it was experimentally investigated that the groundwater of a well is brought to the surface using solar energy, which is one of the renewable energy sources, and the cooling of a place with this water with low energy density. The study evaluated cooling performance on two different days (Exp. 1 and Exp. 2) and at two different cooling water flow rates. The efficiency of the PV system was found to be 8.33±0.44% in Exp. 1 and 8.3±0.44% in Exp. 2. The cooling loads of the cooled buildings differ in Exp. 1 and Exp. 2 due to ambient conditions. The cooling load in Exp. 1 was determined to be 572±22.8 W and in Exp. 2 about 828±33.1 W. The heat loads extracted from the building by the groundwater used as a cooling fluid are 410±16.4 W and 786±31.4 W for Exp. 1 and Exp. 2. The cooling performance evaluation criteria (CPEP) value was found to be 0.72 for Exp. 1 and 0.95 for Exp. 2. Although there was a significant difference between the cooling loads for Exp. 1 and Exp. 2, the cooling load coverage increased with the increase in cooling water flow rate according to the CPEP values. Although in both experiments the cooling load was not fully met and the temperature inside the structure rose slightly during the experiment, it was kept cool.

Keywords:

Solar water pumping, Space cooling, Cooling performance, Efficiency,

PDF

___

E. Özbaş, “Experimental study of thermal performance and pressure differences of different working fluids in two-phase closed thermosyphons using solar energy,” Journal of Polytechnic, vol. 22, no. 1, pp. 121–128, 2018.
P. Sahw and P. Gaur, “Photovoltaic Powered Centrifugal Water Pump,” International Journal of Electronic and Electrical Engineering, vol. 7, no. 3, pp. 247–254, 2014.
M. S. Y. Ebaid, H. Qandil, and M. Hammad, “A unified approach for designing a photovoltaic solar system for the underground water pumping well-34 at Disi aquifer,” Energy Conversion and Management, vol. 75, pp. 780–795, 2013.
P. K. S. Rathore, S. S. Das, and D. S. Chauhan, “Perspectives of solar photovoltaic water pumping for irrigation in India,” Energy Strategy Reviews, vol. 22, pp. 385–395, 2018.
R. Kumar and B. Singh, "Buck-boost converter fed BLDC motor drive for solar PV array based water pumping," 2014 IEEE International Conference on Power Electronics, Drives and Energy Systems (PEDES), 2014, pp. 1-6.
K. Speidel, “Simple water pump, powered by solar energy,” International Symposium–Workshop on Solar Energy June 1978, 1980, pp. 1748–1761.
C. Ramulu, P. Sanjeevikumar, R. Karampuri, S. Jain, A. H. Ertas, and V. Fedak, “A solar PV water pumping solution using a three-level cascaded inverter connected induction motor drive,” Engineering Science and Technology, an International Journal, vol. 19, no. 4, pp. 1731–1741, 2016.
K. M. Bataineh, “Optimization analysis of solar thermal water pump,” Renewable and Sustainable Energy Reviews, vol. 55, pp. 603–613, 2016.
R. Foster and A. Cota, “Solar water pumping advances and comparative economics,” Energy Procedia, vol. 57, pp. 1431–1436, 2014.
A. Saini, Anish; Kohli, Shivam; Pillai, “Solar powered stirling engine driven water pump,” International Journal of Research in Engineering and Technology, vol. 02, no. 11, pp. 615–620, 2013.
N. B. Yousuf, K. M. Salim, R. Haider, M. R. Alam, and F. B. Zia, “Development of a three phase induction motor controller for solar powered water pump,” in Proceedings of 2nd International Conference on the Developments in Renewable Energy Technology, ICDRET 2012, 2012, pp. 312–316.
Renu, B. Bora, B. Prasad, O. S. Sastry, A. Kumar, and M. Bangar, “Optimum sizing and performance modeling of solar photovoltaic (SPV) water pumps for different climatic conditions,” Solar Energy, vol. 155, pp. 1326–1338, 2017.
R. Senol, “An analysis of solar energy and irrigation systems in Turkey,” Energy Policy, vol. 47, pp. 478–486, 2012.
M. A. Hammad, “Characteristics of solar water pumping in Jordan,” Energy, vol. 24, no. 2, pp. 85–92, 1999.
A. K. Daud and M. M. Mahmoud, “Solar powered induction motor-driven water pump operating on a desert well, simulation and field tests,” Renewable Energy, vol. 30, no. 5, pp. 701–714, 2005.
K. Meah, S. Fletcher, and S. Ula, “Solar photovoltaic water pumping for remote locations,” Renewable and Sustainable Energy Reviews, vol. 12, no. 2, pp. 472–487, 2008.
K. Meah, S. Ula, and S. Barrett, “Solar photovoltaic water pumping-opportunities and challenges,” Renewable and Sustainable Energy Reviews, vol. 12, no. 4, pp. 1162–1175, 2008.
S. S. Chandel, M. Nagaraju Naik, and R. Chandel, “Review of solar photovoltaic water pumping system technology for irrigation and community drinking water supplies,” Renewable and Sustainable Energy Reviews, vol. 49, pp. 1084–1099, 2015.
R. H. E. Hassanien, M. Li, and W. Dong Lin, “Advanced applications of solar energy in agricultural greenhouses,” Renewable and Sustainable Energy Reviews, vol. 54, pp. 989–1001, 2016.
V. C. Sontake and V. R. Kalamkar, “Solar photovoltaic water pumping system - A comprehensive review,” Renewable and Sustainable Energy Reviews, vol. 59, pp. 1038–1067, 2016.
T. Arghand, A. Trüschel, J.-O. Dalenbäck, and S. Javed, “Dynamic thermal performance and controllability of fan coil systems,” Cold Climate HVAC Conference, 2018, pp. 351-361.
K. Zhao, X. H. Liu, and Y. Jiang, “Application of radiant floor cooling in a large open space building with high-intensity solar radiation,” Energy and Buildings, vol. 66, pp. 246–257, 2013.
M. Daşkın and İ. G. Aksoy, “Simulation of a solar assisted absorption cooling system for air- conditioning purposes,” Batman University Journal of Life Sciences, vol. 4, no. 1, pp. 52–65, 2014.
R. A. Khan, L. A. Khan, and S. Z. Hussain, “Design and Simulation of 0.75hp Soft Start AC Water Pump Powered by PV Solar System,” Universal Journal of Mechanical Engineering, vol. 3, no. 4, pp. 113–121, 2015.
D. B. Singh, A. Mahajan, D. Devli, K. Bharti, S. Kandari, and G. Mittal, “A mini review on solar energy based pumping system for irrigation,” Materials Today: Proceedings, vol. 43, pp. 417–425, 2020.
M. Altwieb, K. J. Kubiak, A. M. Aliyu, and R. Mishra, “A new three-dimensional CFD model for efficiency optimisation of fluid-to-air multi-fin heat exchanger,” Thermal Science and Engineering Progress, vol. 19, p. 100658, 2020.
Y. Kim and Y. Kim, “Heat transfer characteristics of flat plate finned-tube heat exchangers with large fin pitch,” International Journal of Refrigeration, vol. 28, no. 6, pp. 851–858, 2005.
Y. Vermahmoudi, S. M. Peyghambarzadeh, S. H. Hashemabadi, and M. Naraki, “Experimental investigation on heat transfer performance of Fe2O3/water nanofluid in an air-finned heat exchanger,” European Journal of Mechanics, B/Fluids, vol. 44, pp. 32–41, 2014.
Y. M. Degu, “Cooling Load Estimation and Air Conditioning Unit Selection for Hibir Boat,” The International Journal Of Engineering And Science, vol. 3, no. 5, pp. 63–72, 2014.
K. G. Acharya, G. P. Yewale, M. V. Tendolkar, and S. H. Kulkarni, “Estimation and Analysis of Cooling Load for Indian Subcontinent by CLD/SCL/CLF method at part load conditions,” Journal of Physics: Conference Series, vol. 1240, no. 1, 2019.
M. Ashiq, M. Naveed Gull, R. Kalvin, and M. A. Khan, “Cooling Load Estimation of Auditorium by CLTD Method and its Comparison with HAP and TRACE Software,” Pakistan Journal of Engineering and Technology, vol. 04, no. 01, pp. 18–25, 2021.
S. Zaphar and T. Sheworke, “Computer Program for Cooling Load Estimation and Comparative Analysis with Hourly Analysis Program (HAP) Software,” International Journal of Latest Technology in Engineering, Management & Applied Science, vol. 7, no. 6, pp. 53–61, 2018.
Y. Ji, L. Duanmu, and S. Hu, “Prediction model of air infiltration in single-zone buildings with high airtightness,” Energy and Built Environment, vol. 4, no. 6, pp. 653–668, 2023.
G. T. Tamura, “Measurement of air leakage characteristics of house enclosures,” ASHRAE transactions, vol. 81, no. 1, pp. 202–208, 1975.
I. American Society of Heating Refrigerating and Air Conditioning Engineers, “Cooling and heating load calculation manual,” HUD- PDR-533, Washington, 1980.
M. E. H. Attia, A. E. Kabeel, M. Abdelgaied, F. A. Essa, and Z. M. Omara, “Enhancement of hemispherical solar still productivity using iron, zinc and copper trays,” Solar Energy, vol. 216, pp. 295–302, 2021.
T. Khatib, “Design of photovoltaic water pumping systems at minimum cost for Palestine: A review,” Journal of Applied Sciences, vol. 10, no. 22, pp. 2773–2784, 2010.
